BenchMark® HE Hostile Environment Bench Scale

As of: Monday, August 10, 2026

BenchMark™ HE Hostile Environment Bench Scale

Standard Features

304 stainless steel frame and cover
Base design isolates load cell from overloads and shock loads for added durability
Specially designed adjustable support feet provide exceptional traction and will not scratch surfaces

Approvals

WARNING: Cancer and Reproductive Harm California Proposition 65

Bench Scale For A Hostile Environment

Starting with a stainless steel IP69K hermetically sealed load cell, the HE Series bench scale addresses the needs of hostile environment and washdown applications. Rice Lake's BenchMark HE bench scale performs reliably through the most demanding tasks, with a base that's specially engineered for overload protection. The HE Series design is available on almost any size or capacity.

BenchMark HE Dimensions

Dimensions
Capacity (kg)	Platform Size (L x W mm)	L1	W1	H
30	305 x 457	318	476	102
30	457 x 457	476	476	133
30	305 x 610	476	629	133
60	305 x 457	318	476	133
60	457 x 457	476	476	133
60	457 x 610	476	629	133
60	610 x 610	629	629	133
150	457 x 457	476	476	133
150	457 x 610	476	629	133
150	610 x 610	629	629	140
300	457 x 457	476	476	140
300	457 x 610	476	629	140
300	610 x 610	629	629	140

BenchMark HE Specifications

Load Cell, NTEP Certified:
IP69K stainless steel, hermetically sealed

Output Impedance:
1,000 ohm

Maximum Overload:
150%-200% depending on capacity

Overload Protection:
Five-point, independently adjusted

Cable Length:
3 m

Compensated Temperature Range:
-10° C to 40° C

Warranty:
Three-year limited
(includes water ingress)

Approvals:
NTEP CC 95-072, Class III, 5,000 d
Measurement Canada AM-5082, Class III, 5,000 d
Load cell is FM approved

Part #	Description	List Price
124431	305mm x 457mm 30kg SST (LOAD CELL CABLE LENGTH 3m) OIML C3 Load Cell	Consult
124433	457mm x 457mm 30kg SST (LOAD CELL CABLE LENGTH 3m) OIML C3 Load Cell	Consult
124441	457mm x 610mm 30kg SST (LOAD CELL CABLE LENGTH 3m) OIML C3 Load Cell	Consult
124432	305mm x 457mm 60kg SST (LOAD CELL CABLE LENGTH 3m) OIML C3 Load Cell	Consult
124434	457mm x 457mm 60kg SST (LOAD CELL CABLE LENGTH 3m) OIML C3 Load Cell	Consult
124442	457mm x 610mm 60kg SST (LOAD CELL CABLE LENGTH 3m) OIML C3 Load Cell	List Price: $2,525.00
124449	610mm x 610mm 60kg SST (LOAD CELL CABLE LENGTH 3m) OIML C3 Load Cell	Consult
124438	457mm x 457mm 150kg SST (LOAD CELL CABLE LENGTH 3m) OIML C3 Load Cell	Consult
124446	457mm x 610mm 150kg SST (LOAD CELL CABLE LENGTH 3m) OIML C3 Load Cell	Consult

Part #	Description	List Price
112044	OPT Benchmark, Benchmark (SL/HE/HE-X), CW-80B, CW-90B, CW-90XB to IQ+210, CW-90I, CW-90XI, 480/482, 680/682, 380/380X	List Price: $145.00
112045	OPT Benchmark, Benchmark (SL/HE/HE-X), CW-80B, CW-90B, CW-90XB to IQ+210, CW-90I, CW-90XI,480/482, 680/682, 380/380X	List Price: $195.00
64576	OPT, Benchmark for IQ+210, 480/482, 680/682, 380/380X	List Price: $100.00
22125	Scale	Consult
