Flintec® PA3 Aluminum, Single Point Load Cell

As of: Sunday, August 9, 2026

The PA3 load cell i a high-grade aluminum, single-point. It has capacities of 300 to 5,000 grams and is equipped with 0.5 meters of integrated cable.

WARNING: Cancer and Reproductive Harm California Proposition 65

PA3 Load Cell Specifications

Full Scale Output:
1 mV/V

Output Resistance:
350 (± 10) ohm

Input Resistance:
409 (± 15) ohm

Material Finish:
Aluminum

Temperature:
Compensated:
14 to 104 °F (-10 to 40 °C)
Operating:
0 to 150 °F (-18 to 65 °C)

Seal Type:
Environmentally sealed, IP66

Safe Overload:
150% full scale

Rated Excitation:
5 to 10 VDC

Combined Error:
± 0.05% full scale

Insulation Resistance:
5,000 megohm

Cable Length:
0.5 m

Cable Jacket:
PVC

Color Code:
Green +Excitation
Black -Excitation
White +Signal
Red -Signal
Yellow shield

Max Platform Size:
200 × 200 mm

Warranty:
One-year limited

Rated Capacity	A	B	C	D	E	F	G	H	I	J
g/mm
300 to 5,000	110.0	18.0	33.0	86.0	7.0	5.0	< 3.0	10.0	4 × M3 × 0.5, 9 mm deep	0.5 m, 4 core cable, PVC
