Ishida WM-Micro Compact Wrapper

As of: Friday, July 10, 2026

Standard Features

Process up to 15 packages per minute with manual tray selection
Quick film loading
Compact, space-saving design fits almost anywhere
Wraps most trays between #2 and #25
High-capacity label roll with two times the length of a standard roll
Fixed high-capacity side-load cassette
High-resolution printhead
Prints safe handling instructions, country of origin, 2020 nutrition, custom text messages, custom images and more
Dynamically generated QR code printing
Large customizable color touchscreen with adjustable viewing angle and tactile keypad
Assign color images to preset keys
Display videos with sound
PC-based with a solid-state drive for speed and reliability
Secure remote access
Filter for third-party driver communication
Modes: Wrap and Label, Wrap, Label
Fully compliant with RoHS regulations for a completely lead-free machine
Optional Wi-Fi kit (factory installation recommended)
Linerless model available with auto cutter
Compatible with third-party software, including Upshop 360®, ADC's InterScale®, Invafresh’s ePlum®, Toast®, Square® and Droste®

Approvals

WARNING: Cancer and Reproductive Harm California Proposition 65

Compact Retail Weighing, Wrapping and Labeling

The WM-Micro is a semi-automatic wrapping machine with integrated scale and printer. It’s smaller than a standard hand-wrapping station and can be easily installed in nearly any backroom. Reducing repetitive manual labor for operators, the WM-Micro consistently delivers high-quality wrapping. A large 12.2-inch operator display is easy to read and features a responsive interface powered by LINUX OS to support intuitive operation.

Film and label rolls can be quickly and easily replaced, and the WM-Micro is designed to minimize downtime for cleaning and maintenance.

Wrap a Variety of Trays

The WM-Micro allows operators to weigh, wrap and label up to 15 trays per minute. It is designed to wrap many types of trays, supporting a wide variety of products. It features high-quality and stable wrapping to minimize defects and reduce waste.

Ishida WM-Micro Specifications

Power:
200 to 240V (1-phase)
Standard 20 A circuit

Power Consumption:
In operation: 1,200 W or less
Standby: 1,000 W or less

Resolution:
3,000 display divisions maximum

Communications:
LAN
Static/DHCP
Optional Wi-Fi 802.11a/b/g/n/ac 2.4 GHz/5 GHz
Security: WEP/WPA/WPA2

Input/Output:
LAN
Four USB-A (service, transaction data)

Operating System:
Linux

Memory Capacity:
SSD 1 GB

Preset Keys:
99 dynamically programmed groups with 99 sub pages
19 tactile function keys

Display:
Operator: resistive thin film analogue touch panel, TFT LCD color touchscreen with LED backlight with SVGA, 12.1 in (800 × 600 px)
Unit price: six digits
Tare: four digits
Weight: five digits
Total price: eight digits

Printer:
Printhead: 3.1 in (80 mm) direct thermal, effective 3 in (76mm)
Resolution: 300 dpi (12 dot/mm)
Speed: 4.7 in/sec (120 mm/sec) max
Min. weight: 0.015 lb (0.006 kg)
Formats: customizable, up to 999
Barcodes: UPC, JAN, EAN, EAN128, CODE128, ITF, GS1, QR, Custom

Label Size:
Type: Die-cut, continuous, optional linerless label with kit
Width (with liner): 1.1 to 3.1 in (30 to 80 mm)
Width (linerless): 1 to 3 in (23 to 76 mm)
Length (with liner): 0.9 to 4.1 in (23 to 105 mm)
Length (linerless): 1.1 to 19.6 in (30 to 500 mm)

Label Roll:
I.D.: 1.6-in (40 mm) min
O.D.: 4.9-in (125 mm) max
Backing width: 3.2-in (82 mm) max

Wrapping:
Weigh and wrap: 15 packages per minute max
Width: 5.9 to 15.0 in (150 x 381 mm)
Depth: 5.0 to 9.6 in (127 x 244 mm)
Height: 0.4 to 5.1 in (10 x 130 mm)
Tray height: 1.7-in (45 mm) max
Weight: 0.015 lb (0.006 kg) to 7.7 lb (3.5 kg)
Tray material: Polystyrene Paper (PSP), Polypropylene (PP), Polyethylene Terephthalate (PET)

Film:
Type: PVC, PO, PE
Rolls: One, manual film selection
Length: 5,000 ft (1,524 m)
Width: 400 to 550 mm
O.D.: 7.9 in (200 mm)
Recommended: Mitsubishi A50

Platter:
13.5 × 10 in (343 × 254 mm)

Weight:
Liner: approx. 283.7 lb (128.5 kg)
Linerless: approx. 286.0 lb (129.8 kg)

Temperature:
Operating: 41 °F to 95 °F (5 °C to 35 °C)

Humidity:
20 to 85% RH (without condensation)

Noise:
73 to 75 dB

Warranty:
One-year limited
Based on volume of 900 packs per day using Mitsubishi film

Approvals:
NTEP 06-029
cULus Listed

Ishida WM-Micro Dimensions

Dimensions
A	31.5 in (800 mm) 32.4 in (823 mm) linerless	E	34.1 in (866 mm
B	33.5 in (851 mm)	F	29.8 in (757 mm)
C	28.9 in (734 mm)	G	12.2 in (310 mm)
D	29.1 in (739 mm)	H	16.7 in (424 mm)

Stand
A	26.30 (668 mm)	C	28.00 (711 mm)
B	26.00 (660 mm)

Part #	Description	List Price
223814	Manual label, Single printer, Wired LAN, 220VAC, Ishida	Consult
226173	Linerless label, Single Printer, 220VAC, Ishida	Consult

Part #	Description	List Price
121076	WM-Nano, Stainless Steel, Leveling Legs, Casters, Ishida 28Wx26Dx27H	Consult
125578	WM-Micro, WM-Nano wrapper, 20 rolls POP labels, Ishida	Consult
151761	dispenser, Set of 10, Ishida, use for wider core POP labels	List Price: $30.00
121077	WM-Nano, WM-Micro, plastic, Ishida	Consult
125417	TALL - Cover WM-Nano, WM-Micro Stand and POP Label Option Plastic Ishida	Consult
226175	Protection, SST, (WM-Micro), Ishida	Consult
225984	Rice Lake/Ishida, WM-Micro, Template Mat 35in x 40in	Consult
95540	Interlock 65mm Long OMNi-4000, OMNi-3000, OMNi-3000S, OMNi-3000ST WM-4000, WM-Ai, WM-Micro, Ishida	Consult
160906	Hagiwara, UDG4-1GDRJS, Ishida	Consult

Communication

Part #	Description	List Price
226174	Kit, Silex, SX-590, 2.4 GHz/5 GHz, 802.11b/g, WM-Micro, Ishida	Consult
152628	SLP-5, (perpetual license to a single computer/hard drive, non-transferable between computers/hard drives), Ishida	Consult
78860	RJ45 to RJ45, 7FT	List Price: $44.00

Wrapping Film

Part #	Description	List Price
181916	2 Rolls/Case, 42 Cases/Pallet, 15.7 in Mitsubishi Diawrap, A50 12 Micron Thick - Automatic Wrappers * STAND ROLLS ON ENDS ONLY - ROLLS SUBJECT TO CRUSHING*	Consult
187821	2 Rolls/Case, 42 Cases/Pallet, 17.7 in Mitsubishi Diawrap, A50, 12 Micron Thick - Automatic Wrappers * STAND ROLLS ON ENDS ONLY - ROLLS SUBJECT TO CRUSHING*	Consult
170110	2 Rolls/Case, 42 Cases/Pallet, 19.7 Mitsubishi Diawrap, A50, 12 Micron Thick - Automatic Wrappers * STAND ROLLS ON ENDS ONLY - ROLLS SUBJECT TO CRUSHING *	Consult

Label Stock

Part #	Description	List Price
47341	Thermal Printer 64mm Wide x 50 Meter Roll 1-9/16 Core DIA Sold Per Roll Ishida	List Price: $6.00
47732	UPC 60mm x 44mm (2.36" x 1.73") DTL Small Core 2 Color Red/Blue 800 LPR 12 RPC Ishida	List Price: $106.00
47733	UPC 64mm x 47mm (2.52" x 1.85") DTL Small Core 2 Color Red & Yellow 800 LPR 12 RPC Ishida	List Price: $106.00
47735	Text 64mm x 59mm (2.52" x 2.32") DTL Small Core 2 Color 625 LPR 12 RPC Ishida	List Price: $106.00
105419	Text w/Safe Handling Use or Freeze By 64mm x 59mm DTL Small Core 2 Color Red & Blue 625 LPR 12 RPC	List Price: $106.00
47736	Text w/Safe Handling 64mm x 59mm (2.52" x 2.32") DTL 625 LPR Small Core 2 Color 12 RPC Ishida	List Price: $106.00
108087	DTL Safe Handling 500 LPR Small Core 2 Color Blue and Red 12 RPC	List Price: $106.00
47743	Extended Text 64mm x 85mm (2.52" x 3.34") DTL 2 Color 425 - 450 LPR 1-5/8 Core 12 RPC Ishida	List Price: $106.00
47745
