Rice Lake Analog Retrofit Kit for B-Tek
As of: Sunday, November 8, 2026
Standard Features
Complete Kit Includes
Eight or 10 Rice Lake NTEP Certified stainless steel, hermetically sealed, rocker column load cells
Upper and lower cups
Grounding straps
NEMA Type 4X signal trim junction boxes
100 ft of hostile environment EL147HE SURVIVOR® load cell cable
Standard Features
Load cells are NTEP Certified 1:10,000 divisions, Class IIIL*
Converts B-TEK digital CPD-M scales to analog
Load cells have built-in surge protection and rated to IP69K
Stainless steel overbraid cable
Two-year limited warranty
*Consult your local Weights & Measures Authorities for local Legal for Trade requirements
Applications
B-TEK digital truck scale conversion
Stainless Steel, Legal for Trade Retrofit Kit
The B-TEK digital retrofit kit is designed to be a cost-effective solution for converting B-TEK digital CPD-M truck scales to analog scales. The replacement load cells are stainless steel, hermetically sealed rocker column load cells designed to provide years of reliable service.
Dimensions
Analog Load Cell Dimensions | |
|---|---|
A | Ø2.75 in (70 mm) |
B | Ø1.18 in (30 mm) |
C | Ø2.50 in (64 mm) |
D | 0.59 in (15 mm) |
E | 1.77 in (45 mm) |
F | 8.48 in (215 mm) |
G | 2.23 in (57 mm) |
H | 0.55 in (14 mm) |
I | Ø1.73 in (44 mm) |
| Part # | Description | List Price |
|---|---|---|
| 216423 | Conversion Kit From B-Tek CPD-M Digital Load Cell To RL82021-40t Rocker Cell. Kit Includes 8-RL82021-40t Stainless Rocker Cells, 8 Mild Steel Upper Cups And 8 Mild Steel Lower Cups. 8 Bonding Straps, 100FT Cable And 2 EL304A Junction Boxes. | List Price: $7,795.00 |
| 216424 | Conversion Kit From B-Tek CPD-M Digital Load Cell To RL82021-40t Rocker Cell. Kit Includes 10-RL82021-40t Stainless Rocker Cells, 10 Mild Steel Upper Cups And 10 Mild Steel Lower Cups. 10 Bonding Straps, 100FT Cable And 3 EL304A Junction Boxes. | List Price: $9,875.00 |
