Rice Lake RL1385 Stainless Steel, Single-point Load Cell
As of: Tuesday, July 21, 2026
Standard Features
Low-profile, off-center loading load cell. Designed for direct mounting on weighing platforms, hanging scales and other low-capacity beam applications. Stainless steel construction with a humidity-resistant protective coating provides long-term stability, even in harsh environments. Potted cavities provide improved performance in damp environments. Capacities range from 10 to 200 kg. Complete with 10 ft of load cell cable. The 100,000 and 200,000 kg capacities are not NTEP Certified.
RL1385 Load Cell Specifications
|
Full Scale Output: Output Resistance: Input Resistance: Material/Finish: Temperature: Seal Type: |
Safe Overload: Rated Excitation: Combined Error: Insulation Resistance: Cable Length: Cable Diameter: |
Cable Color Code: Max Platform Size: Warranty: Approvals: |
RL1385 Load Cell Dimensions
| Rated Capacity | H | H1 | L | L1 | L2 | L3 | L4 | L6 | W | T | T2 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| kg/mm | |||||||||||
| 10 to 100 | 40.0 | 10.0 | 150.0 | 100.0 | 19.0 | 32.0 | 6.0 | 20.0 | 25.4 | 1/4-20 UNC × 19.1 DP | N/A |
| 200 | 40.0 | 10.0 | 150.0 | 100.0 | 19.0 | 32.0 | 6.0 | 20.0 | 38.1 | 1/4-20 UNC × 19.1 DP | 25.4 |
NTEP Certified
| Part # | Description | List Price |
|---|---|---|
| 41405 | 10kg 3M 2mV/V 350 OHM NTEP III 3 S SST IP67 | List Price: $328.00 |
| 41233 | 3M 2mV/V 350 OHM NTEP III 3 S SST IP67 | List Price: $328.00 |
| 41234 | 3M 2mV/V 350 OHM NTEP III 3 S SST IP67 | List Price: $328.00 |
| 41235 | 3M 2mV/V 350 OHM NTEP III 3 S SST IP67 | List Price: $328.00 |
| 41236 | 3M 2mV/V 350 OHM NTEP III 3 S SST IP67 | List Price: $328.00 |
Non-NTEP Certified
| Part # | Description | List Price |
|---|---|---|
| 41237 | 100kg 3M 2mV/V 350 OHM SST IP67 | List Price: $310.00 |
| 41406 | 200kg 3M 2mV/V 350 OHM S SST IP67 | List Price: $477.00 |
