Rice Lake RL32011WB-L, Single-Ended Beam Load Cell

RL32011WB-L Load Cell Specifications

Full Scale Output:
2.0 (±0.1%) mV/V

Output Resistance:
350 (±3) ohm

Input Resistance:
385 (±10) ohm

Material/Finish:
Stainless steel

Temperature:
Compensated:
14 to 104 °F (-10 to 40 °C)
Operating:
0 to 150 °F (-18 to 65 °C)

Seal Type:
Environmentally sealed, IP67

Safe Overload:
150% full scale

Safe Sideload:
100% full scale

Rated Excitation:
5 to 10 VDC

Combined Error:
0.02% full scale

Non-repeatability:
± 0.01% full scale

Insulation Resistance:
5,000 megohm

Cable Length:
20 ft

Cable Diameter:
0.190 in
Polyurethane jacket

Cable Color Code:
Green +Excitation
Black -Excitation
White +Signal
Red -Signal

Warranty:
Two-year limited

Approvals:
NTEP 11-024

Rated Capacity	A	B	C	D	E
lb/in
1,250	11.50	7.12	8.52	1.25	3.0
5,000	10.9	5.5	7.4	2.0	3.0
10,000	12.6	5.9	8.0	2.5	3.0

Rated Capacity

lb/in

1,250

11.50

7.12

8.52

1.25

3.0

5,000

10.9

5.5

7.4

2.0

3.0

10,000

12.6

5.9

8.0

2.5

3.0

Part #	Description	List Price
119788	1.25k 1250lb 20ft 2mv/v 350 Ohm SST EW NTEP III 5 M IP67 Link	List Price: $730.00
119790	5k 5000lb 20ft 2mv/v 350 Ohm SST EW NTEP III 5 M IP67 Link	List Price: $850.00
119791	10k 10000lb 20ft 2mv/v 350 Ohm SST EW NTEP III 5 M IP67 Link	List Price: $950.00

Part #

Description

List Price

119788

1.25k 1250lb 20ft 2mv/v 350 Ohm SST EW NTEP III 5 M IP67 Link

List Price: $730.00

119790

5k 5000lb 20ft 2mv/v 350 Ohm SST EW NTEP III 5 M IP67 Link

List Price: $850.00

119791

10k 10000lb 20ft 2mv/v 350 Ohm SST EW NTEP III 5 M IP67 Link

List Price: $950.00

Full Scale Output:
2.0 (±0.1%) mV/V

Output Resistance:
350 (±3) ohm

Input Resistance:
385 (±10) ohm

Material/Finish:
Stainless steel

Temperature:
Compensated:
14 to 104 °F (-10 to 40 °C)
Operating:
0 to 150 °F (-18 to 65 °C)

Seal Type:
Environmentally sealed, IP67

Safe Overload:
150% full scale

Safe Sideload:
100% full scale

Rated Excitation:
5 to 10 VDC

Combined Error:
0.02% full scale

Non-repeatability:
± 0.01% full scale

Insulation Resistance:
5,000 megohm

Cable Length:
20 ft

Cable Diameter:
0.190 in
Polyurethane jacket

Cable Color Code:
Green +Excitation
Black -Excitation
White +Signal
Red -Signal

Warranty:
Two-year limited

Approvals:
NTEP 11-024

Rice Lake RL32011WB-L, Single-ended Beam Load Cell

Standard Features

Approvals

RL32011WB-L Load Cell Specifications

RL32011WB-L Load Cell Dimensions
