Rice Lake RL32022 Alloy Steel, Single-ended Beam Load Cell

As of: Monday, July 27, 2026

Standard Features

The RL32022 is a metric version of the RL32018 load cell. Constructed of alloy steel and sealed to IP67 standards. OMIL approved capacities range from 300 to 2,000 kg. Complete with 5 m of load cell cable.

Approvals

WARNING: Cancer and Reproductive Harm California Proposition 65

RL32022 Load Cell Specifications

Full Scale Output:
2.0 mV/V ±0.05%
mV/V/ohm calibration

Output Resistance:
350 (±3) ohm

Input Resistance:
400 (±20) ohm

Material/Finish:
Alloy steel, nickel plated

Temperature:
Compensated:
-14 °F to 104 °F (-10° C to 40° C)
Operating:
0 °F to 150 °F (-18 °C to 65 °C)

Seal Type:
Environmentally sealed, IP67

Safe Overload:
150% full scale

Safe Sideload:
100% full scale

Rated Excitation:
10 VDC (15 V maximum)

Combined Error:
0.017% full scale

Insulation Resistance:
>5,000 megohm

Deflection at Capacity:
0.2 to 0.4 mm

Cable Length:
5 m

Cable Color Code:
Green +Excitation
Black –Excitation
Red +Signal
White –Signal

Warranty:
Two-year limited

Approvals:
OIML R60/2017-A-NL1-22.11

RL32022 Load Cell Dimensions

Rated Capacity	A	B	C	D	E	F	G	H	I	J	K	L	M	N
kg/mm
300 to 2,000	31.5	15.0	34.6	56.0	31.5	130.0	13.5	18.0	M12	76.2	25.4	15.8	6.5	3.5

Part #	Description	List Price
211630	300kg 2mv 350 Ohm 5m Alloy Steel C3 OIML IP67	List Price: $315.00
211631	500kg 2mv 350 Ohm 5m Alloy Steel C3 OIML IP67	List Price: $315.00
211632	750kg 2mv 350 Ohm 5m Alloy Steel C3 OIML IP67	List Price: $315.00
211633	1000kg 2mv 350 Ohm 5m Alloy Steel C3 OIML IP67	List Price: $315.00
211634	1500kg 2mv 350 Ohm 5m Alloy Steel C3 OIML IP67	List Price: $315.00
211635	2000kg 2mv 350 Ohm 5m Alloy Steel C3 OIML IP67	List Price: $315.00
