RL3423 Alloy Steel, S-Beam Load Cell

Full Scale Output:
2,0 mV/V ± 0.1% mV/V

Output Resistance:
50 ohms ± 3

Input Resistance:
350 ohms ± 3

Material/Finish:
Alloy steel

Temperature:
-30° C to 70° C

Seal Type:
Welded seal, IP67

Rated Excitation:
5–15 VDC max.

Insulation Resistance:
> 5000 Megohms

Cable Length:
5 m

Cable Color Code:
Red    +    Excitation
Black    –    Excitation
Green    +    Signal
White    –    Signal
Yellow    +    Sense
Blue    –    Sense

Warranty:
One-year limited warranty

Approvals:
OIML
CE
