RLPLS-125K-mA Alloy Steel, Environmentally Sealed Load Cell

Material/Finish:
Alloy steel

Output:
2-20 mA

Temperature:
14° F to 104° F (-10° C to 40° C)

Insulation Resistance:
2,000 megohms at 50 VDC

Seal Type:
Environmentally sealed, IP66

Connector Type:
Turck 7/8 in minifast, 5-pin

Warranty:
One-year limited warranty

Connector Pin Out:
Pin 1: Loop Power
Pin 2: Current Loop
Pin 3: Shield Pin
Pin 4: NC Pin
Pin 5: Ground
