RLPLS-75K Alloy Steel, Hermetically Sealed Load Cell

Material/Finish:
Alloy steel

Output:
2 to 10 mA - PN 115199 and PN 151456
2 to 20 mA - PN 169221

Temperature:
14° F to 104° F (-10° C to 40° C)

Insulation Resistance:
2,000 megohms at 50 VDC

Seal Type:
Hermetically sealed, IP68

Connector Type:
Turck 7/8 in minifast, 5-pin (x2)

Connector Pin Out:
Pin 1: Loop Power
Pin 2: Current Loop
Pin 3: Shield
Pin 4: NC
Pin 5: Ground

Warranty:
One-year limited warranty
