VPG® Sensortronics® 65061A Alloy/Stainless Steel, Double-ended Beam Load Cell
As of: Wednesday, July 8, 2026
Standard Features
This unique double-ended beam has been a standard model in Fairbanks Scales® truck scales for years. This NTEP Certified, zinc-plated, alloy steel load cell is sealed with a potting compound that has been proven through the test of time in numerous applications. Capacities available in 40,000 and 50,000 lb. Complete with 60 ft of copper overbraid load cell cable.
This module is available upon request as a stainless steel, welded-seal with a 50,000 capacity.
65061A Load Cell Specifications
|
Full Scale Output: Output Resistance: Input Resistance: Material/Finish: Temperature: |
Seal Type: Safe Overload: Safe Sideload: Rated Excitation: Combined Error: Insulation Resistance: |
Cable Length: Cable Diameter: Cable Coloring: Warranty: Approvals: |
65061A Load Cell Dimensions
| Rated Capacity | A | B | C | D | E | F |
|---|---|---|---|---|---|---|
| lb/in | ||||||
| 40,000 | 1.94 | 2.44 | 8.75 | 0.78 | 10.50 | 0.257 × 0.375 DP |
| 50,000 | 1.94 | 2.44 | 8.75 | 0.78 | 10.50 | 0.257 × 0.375 DP |
Alloy Steel
| Part # | Description | List Price |
|---|---|---|
| 47850 | 1108 40000lb 60ft 3mV/V 700 Ohm WW NTEP IIIL 10M IP67 | List Price: $1,275.00 |
| 47851 | 1108 50000lb 60ft 3mV/V 700 Ohm WW NTEP IIIL 10M IP67 alloy steel | List Price: $1,275.00 |
| 154800 | 1111 50,000lb 60ft 3mv/v 700 Ohm MS NTEP IIIL 10M IP67 | List Price: $1,275.00 |
Stainless Steel
| Part # | Description | List Price |
|---|---|---|
| 67387 | 1107 50,000lb 60ft 3mv/v 700 OHM SST NTEP IIIL 10M IP67 | List Price: $1,425.00 |
Mounting Assembly Accessories
| Part # | Description | List Price |
|---|---|---|
| 25524 | Load Cell. Not to be used with load cell with counterbore load hole. | List Price: $53.00 |
| 50807 | 1-3/4 DIA x 4-1/16 Long | List Price: $101.00 |
| 44837 | UNC x 2.35 Long | List Price: $134.00 |
| 50748 | Mild Steel Plated Fairbanks Rodan | List Price: $42.00 |
| 50767 | Machined And Painted Fairbanks Rodan Truck Scale | List Price: $337.00 |
| 50747 | 4.50 Long Fairbanks Rodan | List Price: $37.00 |
| 15180 | ID=.812 OD=1.750 Thickness=.109 | List Price: $2.30 |
| 15244 | Extended Prong Steel Zinc Plated | List Price: $1.50 |
| 154802 | Scale with counterbore load hole Stainless Steel | List Price: $45.00 |
