VPG Tedea-Huntleigh 1240 Stainless Steel, Single Point Load Cell

Compact in design, this low-profile, single point load cell is ideally suited for light-industrial or people-weighing applications where deck height is a concern. The three-beam design makes the load cell less susceptible to side forces and mounting imperfections. It features stainless steel construction and humidity-resistant coating for use in harsh environments with extreme temperatures. Units are available in capacities ranging from 200 to 250 kilograms and are equipped with 3 meters of load cell cable.

Full Scale Output:
2.0 mV/V

Output Resistance:
351 (±5) ohms

Input Resistance:
380 (±15) ohms

Material/Finish:
Stainless steel

Temperature:
Operating:
0 to 150 °F (-18 to 65 °C)

Seal Type:
Environmentally sealed, IP64

Safe Overload:
150% full scale

Rated Excitation:
5 to 10 VDC (15 V maximum)

Combined Error:
0.02% full scale

Insulation Resistance:
2,000 megohm

Deflection at Capacity:
0.015 in

Cable Length:
10 ft

Cable Diameter:
0.200 in
PVC jacket

Cable Color Code:
Green +Excitation
Black -Excitation
Red +Signal
White -Signal
Blue +Sense
Brown -Sense

Max Platform Size:
15.5 × 15.5 in

Warranty:
One-year limited

Approvals:
cFMus

Rated Capacity	A	B	C	D	E	F	G	I	J	H	M
kg/mm
200 to 250	150.1	39.9	86.6	43.4	38.1	25.4	6.35	25.4	38.1	1/4-20 UNC x 13 DP	1/4-28 UNF x 10 DP

Part #	Description	List Price
47880	3.1M TH 2mV/V 350 OHM FM SST IP64	List Price: $575.00
47881	3.1M TH 2mV/V 350 OHM FM SST IP64	List Price: $575.00
