BenchPro™ BP-R Retail Digital Bench Scale

  • Large six-digit backlight LCD display with 1 in (29 mm) characters protected by heavy-duty tempered glass
  • Powered USB HID point of sale interface – plug and play USB interface provides power and communications
  • Nine-pin RS-232 interface for use with SMA, NCI and ECR
  • Four AA alkaline battery operation for portability (BP-R 12 x 14 scale only) (batteries not included)
  • Gravitational compensation allows for adjustment of factory calibration to meet your local gravity setting, non-approved

Approvals

Some approval documents are available to view by clicking the icons below.

NTEP Logo CE Mark

WARNING: Cancer and Reproductive Harm California Proposition 65

Dynamic Response:
0-1000d, 1.0 sec, maximum average
1000d +, 1.5 sec, maximum average

Power:
In-line Power Supply
Input: 100-240 VAC, +10% -15%, 3-wire w/ground Standard terminated with USA 3-prong plug
Output: 12 V at .1 Amps DC minimum
Frequency: 50/60 Hz +/-3 Hz, standard
Approvals: UL, CE, EN, CUL

Battery Power - BP 1214 Series Only:
Battery Type: Four AA alkaline batteries (not included)
Approx Life: 250 hrs (sleep mode) or 80 hrs (continuous use) Backlight on 80 hrs (sleep mode) or 50 hrs (continuous use)

Construction:
BP Series 0602 and 1010 - Powder coat painted mild steel base plate and load bridge with stainless steel weight platter
BP Series 1214 - DieCast aluminum load bridge and base housing with stainless steel weight platter

Display:
Minimum key press life of 500,000 cycles, ABS plastic housing with Zero, Gross/Brutto, Net, W1/W2/W3 annunciators.

Dimensions:
(L x W x D) 5.25 x 2.21 x 1.09 in Includes an 18 in cable with RJ-45 connection to scale

RS-232 Cable:
10 ft DB 9-pin male to female, straight pass through and null modem

USB Cable:
46 in (1,168.4 mm) A/B type USB cable

USB HID:
USB 2.0 full speed; Vendor ID: 1C19;
Product ID: 0002

Cleaning:
Use of mild soap and water with a wet cloth

Approvals:
NTEP COC# 17-202
CE
Canada Weights and Measures: AM - 6050

Warranty:
Two-year limited warranty

Dimensions/Inches
  A B C D
6 x 10 6.0 10.0 9.0 2.4
10 x 10 10.0 10.0 13.0 2.5
12 x 14 12.0 14.0 14.5 2.7

Resources / Downloads

Title Download Email
BenchPro BP-R Retail Scale Catalog Page Download Email

Title Version Revision Download Email Category Archived
BenchPro Retail BP-R Scales Operation Manual D Download Email Retail Equipment|Countertop POS Scales No

Title Collateral Wizard Request Download Email Category
BenchPro Series - Retail Request Download Email Retail Equipment|Countertop POS Scales

Title View Download Email Category
BenchPro™ Retail Scale Tare Demonstration View Download Email Countertop POS Scales

Parts

BP 0610 Series – 6 x 10 in weight platter

Part # Description List Price Cart
182374 Scale, Bench Pro Series Model BP 0610-6R, 15 x 0.005lb/6 x 0.002kg, SS Weight Platter 6 in x 10 Dimensions

List Price: $730.00

182375 Scale, Bench Pro Series Model BP 0610-15R, 30 x 0.01lb/15 x 0.005kg, SS Weight Platter 6 x 10 in Dimensions

List Price: $730.00

BP 1010 Series – 10 x 10 in weight platter

BP 1214 Series – 12 x 14 in Weight Platter

Options

Part # Description List Price Cart
183103 Mount,Display Bench Pro Scale 16in Stand

List Price: $215.00

174783 Bracket and Post, Option Bench Pro Series, Model BP 1214

List Price: $50.00

180901 Display,Customer Bench Pro Series, with 68in cable and capacity labels

List Price: $72.00

174784 Remote Display,Bench Pro Series, with 68in cable and capacity labels 53YJ90

List Price: $88.00

178501 USB Serial Adapter FTDI US232R-100, 3.28 ft, iDIm 100

List Price: $50.00

196179 Cable,Wedgelink SP Hardware Wedge for Direct RS-232 output. 9600-N-8-1 Baud Rate and Communication Parameters

List Price: $247.00

Replacement Parts

Replacement parts can only be purchased through trained and authorized dealers. You must be logged in as a dealer to view any available replacement parts.

To locate a dealer in your area, please call us at 1-800-472-6703 or fill out a request online.
