Carbon steel
Bright zinc and clear chromate plating for corrosion resistance
Active ball suspension provides ideal load cell loading with maximum side load protection
Hardened alloy steel with plated finish
Includes one carbon steel jam nut and one foot
Top of stud is machined undersized 10% for easy alignment into load cell plus slotted for top-access applications
Stainless steel
Provides outstanding accuracy, repeatability and performance
Active ball suspension provides optimal load cell performance
Hardened stainless steel material, welded with polished finish
Includes one carbon steel jam nut and one foot
Top of stud is machined undersized 10% for easy alignment into load cell plus slotted for top-access applications
| Part # | Description | List Price | Cart/Quote |
|---|---|---|---|
| 74578 | Foot,Floor Scale Carbon Steel Captured Ball 1.875Dia 1/2-20 UNF Thread, 3.500 Height | List Price: $45.00 | |
| 74579 | Foot,Floor Scale Carbon Steel Captured Ball 2.000Dia 1/2-20 UNF Thread, 3.500 Height | List Price: $45.00 | |
| 74580 | Foot,Floor Scale Carbon Steel Captured Ball 2.500Dia 1/2-20 UNF Thread, 3.500 Height | List Price: $45.00 | |
| 74581 | Foot,Floor Scale Carbon Steel Captured Ball 3.000Dia 1/2-20 UNF Thread, 3.500 Height | List Price: $45.00 | |
| 74582 | Foot,Floor Scale Carbon Steel Captured Ball 3.000Dia 3/4-16 UNF Thread, 4.500 Height | List Price: $56.00 | |
| 74583 | Foot,Floor Scale Carbon Steel Captured Ball 3.000Dia 1-12 UNF Thread, 4.500 Height | List Price: $67.00 | |
| 74584 | Foot,Floor Scale Carbon Steel Captured Ball 3.000Dia 1-14 UNF Thread, 4.500 Height | List Price: $67.00 | |
| 171449 | Foot,Floor Scale Carbon Steel Captured Ball 3.00 Dia 1-14 UNF Thread, 5.0 Height To Include Milled In Wrench Flats | List Price: $83.00 | |
| 173018 | Foot, Floor Scale Carbon Steel Captured Ball 4.40 DIA 3/4-16UNF x 3.13 Tall Fully Threaded Stem Zinc Plated | List Price: $96.00 | |
| 174937 | Foot, Floor Scale Carbon Steel Captured Ball 5.40 DIA 3/4-16UNF x 4.13 Tall Fully Threaded Stem Zinc Plated | List Price: $139.00 |
