CW-90XB Light-capacity Bench Scale

  • 304 stainless steel construction
  • Meets HACCP requirements
  • Five-point overload protection
  • Specially designed adjustable support feet provide exceptional traction and will not scratch surfaces
  • IP69K, stainless steel hermetically sealed load cell

Approvals

Some approval documents are available to view by clicking the icons below.

NTEP Logo LOGO Measurementcanada Approved BW LOGO FM CUS LOGO NSF CMYK

WARNING: Cancer and Reproductive Harm California Proposition 65

Load Cell, NTEP Certified:
IP69K stainless steel and hermetically sealed

Output Impedance:
350 ohm

Maximum Overload:
180% to 200% depending on capacity

Overload Protection:
Five-point, independently adjusted

Scale Frame:
AISI304L, straight line finish, Ra=45 +/- 10

Scale Cover:
AISI304L, straight line finish, Ra=45 +/- 10

Cable Length:
34 in or 10 ft

Compensated Temperature Range:
14 °F to 104 °F (-10 °C to 40 °C)

Warranty:
Three-year limited (includes water ingress)

Approvals:
NTEP CC 95-072, Class III 5,000 d
Measurement Canada AM-5082
Load cell is cFMus approved
NSF approved

10 x 10 Dimensions
A 4.25 in (108 mm) C 10.00 in (254 mm)
B 10.00 in (254 mm) C1 10.25 in (260 mm)
B1 10.25 in (260 mm)



12 x 12 Dimensions
A 4.25 in (108 mm) C 12.00 in (305 mm)
B 12.00 in (309 mm) C1 12.25 (311 mm)
B1 12.25 (311 mm)

Resources / Downloads

Title Download Email
CW-90XB Catalog Page Download Email

Title Version Revision Download Email Category Archived
CW-90B and CW-90XB Technical Manual A Download Email Checkweighers|Bench Scales|Indicators / Controllers|Weight Indicators No

Title Download Email
Bench Scale Questionnaire Download Email

Title Collateral Wizard Request Download Email Category
BenchMark Series Bench Scales Collateral Wizard Request Download Email Platform Scales|Bench Scales
CW-90X Over/Under Checkweigher Request Download Email Bench Scales|Checkweighers|Indicators / Controllers
Cannabis Market Weighing Solutions: From Cultivation to Retail Request Download Email Retail Equipment|Checkweighers

Title View Download Email Category
Overload Protection with BenchMark Bench Scales View Download Email Bench Scales

Parts

Cable length: 10 ft

Part # Description List Price Cart
112600 Bench Scale ASSY,5lb CW90X 10x10 (Load Cell Cable Length Is 10ft)

List Price: $1,222.00

112602 Bench Scale ASSY,10lb CW90X 10x10 (Load Cell Cable Length Is 10ft)

List Price: $1,222.00

112604 Bench Scale ASSY,25lb CW90X 10x10 (Load Cell Cable Length Is 10ft)

List Price: $1,222.00

112606 Bench Scale ASSY,25lb CW90X 12X12 (Load Cell Cable Length Is 10ft)

List Price: $1,312.00

112608 Bench Scale ASSY,50lb CW90X 12x12 (Load Cell Cable Length Is 10ft)

List Price: $1,312.00

112610 Bench Scale ASSY,100lb CW90X 12x12 (Load Cell Cable Length Is 10ft)

List Price: $1,312.00

Cable length: 34 ft

Options

Part # Description List Price Cart
112044 Column,12 Inch SST Kit OPT Benchmark, Benchmark (SL/HE), CW-80B, CW-90B, CW-90XB to IQ+210, CW-90I, CW-90XI, 480/482 Legend Series,680 Synergy Series 380 Synergy Series

List Price: $145.00

112045 Column,18 Inch SST Kit OPT Benchmark, Benchmark (SL/HE), CW-80B, CW-90B, CW-90XB to IQ+210, CW-90I, CW-90XI,480/482 Legend Series, 680 Synergy Series 380 Synergy Series

List Price: $195.00

196363 Column,12 Inch SST Kit OPT Benchmark, Benchmark (SL/HE), CW-80B, CW-90B, CW-90XB to 882IS/882IS PLUS with battery

List Price: $225.00

196364 Column,18 Inch SST Kit OPT Benchmark, Benchmark (SL/HE), CW-80B, CW-90B, CW-90XB to 882IS/882IS PLUS with battery

List Price: $275.00

197482 Column,12 Inch SST Kit OPT Benchmark, Benchmark (SL/HE), CW-80B, CW-90B, CW-90XB to 882IS/882IS PLUS with power supply option (power supply will not be mounted to the column), 880/880 Plus Universal

List Price: $165.00

197484 Column,18 Inch SST Kit OPT Benchmark, Benchmark (SL/HE), CW-80B, CW-90B, CW-90XB to 882IS/882IS PLUS with power supply (power supply will not be mounted to the column), 880/880 Plus Universal

List Price: $215.00

64576 Bracket,Attachment Kit OPT, Benchmark for IQ+210, 480/482 Legend Series, 680 Synergy Series, 380 Synergy Series

List Price: $100.00

NA Ball transfer and roller conveyor top

Call for price

Replacement Parts

Replacement parts can only be purchased through trained and authorized dealers. You must be logged in as a dealer to view any available replacement parts.

To locate a dealer in your area, please call us at 1-800-472-6703 or fill out a request online.
