iDimension SS Integration Software

  • Real-time data access and triggering via REST API Swagger API development toolkit included
  • Supported peripherals include barcode scanners and label printers
  • Measurement database – configurable for capturing and transferring:
    • Identification #, i.e. Pro or sales order number
    • Dimensions L × W × H
    • Scale or manual keyboard entry weight
    • Volume
    • Three configurable user fields
    • Color high resolution images
    • Bounding box images
    • Volumetric conversion
    • Email notification alerts
    • Error logging
  • Digital remote I/O configuration for use with PLCs
  • Shipping method analyzer for girth and volume analysis thresholds in conjunction with the iDimension SS real-time display desktop application
  • Local data storage
  • Automatic data export, options include FTP and SMB, configurable
  • Data export, including image format composition and annotations available in data export provides output in CSV, JSON, XML and TXT file formats
  • QR code display for alternate input into MRP, TMS and WMS systems
  • Error logging with high resolution image capture
  • Role-based security model protects data and prevents unwanted configuration changes
  • Comprehensive application log files available to download
  • Forklift database for use with Stop & Go

SQLite database maximum size capabilities is dependent upon file system type.

iDimension SS is a robust, dynamic application for managing scan data captured by iDimension dimensioning solutions.

Scan data, including dimensions, images, weights & bar codes, can be stored locally and custom data export features allow easy and automatic export for use with the of WMS, TMS and shipping software solutions.

Use iDim SS as a standalone data management solution or integrate via the REST API or customizable data export features for all iDimension Series devices installed on your network.

  • Windows 10 build 1607 or newer (64-bit only)
  • 2.0 GHz processor or faster
  • 250 MB hard disk space needed for install
  • 8 GB RAM or greater
  • Ethernet TCP/IP communication to dimensioning devices plus optional scanners, printers and Rice Lake Weighing 680, 880 and 1280 scale indicators
  • Supported web browser (Chrome, Microsoft Edge, Firefox, Safari)

Resources / Downloads

Title Download Email
iDimension SS Catalog Page Download Email

Title Version Revision Download Email Category Archived
iDimension Software Suite Software Manual A Download Email Dimensioning No

Title Download Email
Dimensioning-Rental Lease Program Questionnaire Download Email

Title View Download Email Category
What is Dimensional Weight and Why is it Important? View Download Email Dimensioning|Packages and Parcels Dimensioning|Pallets and Freight Dimensioning


Part # Description List Price Cart
203010 iDimension Desktop Wedge for Windows PC. Download available at

Call for price

175812 Software,iDimension SS Webserver, database collection and integration program

List Price: $2,250.00

201447 Software,iDimension SS real-time status display desktop application

List Price: $250.00

201448 Software,iDimSS Data Mgmt Forklift Data Management Software

List Price: $250.00
