The ITCM Series utilizes several Rice Lake Weighing Systems components to provide an unmatched level of performance in tank and hopper weighing applications and mechanical scale conversions. The ITCM incorporates clevis and unique rod-end ball joint assemblies to reduce the overall length to less than half of the traditional tension cell mounts, while providing correct load alignment. In addition, the load cell is completely electrically isolated from stray currents, which are a major cause of load cell failure. To complete the design, a grounding strap connects the two clevis assemblies to further provide safety to your load cells.
| Part # | Description | List Price | Cart/Quote |
|---|---|---|---|
| 17851 | Mount ASSY,ITCM 100 lb 3/8-16UNC Mild Steel Zinc Plated Tension INCL RL20000-100 lb | List Price: $566.00 | |
| 17831 | Mount ASSY,ITCM 100 lb 1/2-13UNC Mild Steel Zinc Plated Tension INCL RL20000-100 lb | List Price: $566.00 | |
| 30337 | Mount ASSY,ITCM 150 lb 3/8-16UNC Mild Steel Zinc Plated Tension INCL RL20000-150LB | List Price: $566.00 | |
| 30336 | Mount ASSY,ITCM 150 lb 1/2-13UNC Mild Steel Zinc Plated Tension INCL RL20000-150LB | List Price: $566.00 | |
| 30335 | Mount ASSY,ITCM 200 lb 3/8-16UNC Mild Steel Zinc Plated Tension INCL RL20000-200LB | List Price: $566.00 | |
| 30338 | Mount ASSY,ITCM 200 lb 1/2-13UNC Mild Steel Zinc Plated Tension INCL RL20000-200LB | List Price: $566.00 | |
| 17852 | Mount ASSY,ITCM 250 lb 3/8-16UNC Mild Steel Zinc Plated Tension INCL RL20000-250 lb | List Price: $566.00 | |
| 17832 | Mount ASSY,ITCM 250 lb 1/2-13NC Mild Steel Zinc Plated Tension INCL RL20000-250 lb | List Price: $566.00 | |
| 17853 | Mount ASSY,ITCM 500 lb 1/2-13NC Mild Steel Zinc Plated Tension INCL RL20000-500 lb | List Price: $619.00 | |
| 17858 | Mount ASSY,ITCM 500 lb 5/8-11NC Mild Steel Zinc Plated Tension INCL RL20000-500 lb | List Price: $619.00 | |
| 17833 | Mount ASSY,ITCM 500 lb 3/4-10NC Mild Steel Zinc Plated Tension INCL RL20000-500 lb | List Price: $619.00 | |
| 17854 | Mount ASSY,ITCM 750 lb 1/2-13NC Mild Steel Zinc Plated Tension INCL RL20000-750 lb | List Price: $619.00 | |
| 17859 | Mount ASSY,ITCM 750 lb 5/8-11NC Mild Steel Zinc Plated Tension INCL RL20000-750 lb | List Price: $619.00 | |
| 17834 | Mount ASSY,ITCM 750 lb 3/4-10NC Mild Steel Zinc Plated Tension INCL RL20000-750 lb | List Price: $619.00 | |
| 17855 | Mount ASSY,ITCM 1,000 lb 1/2-13NC Mild Steel Zinc Plated Tension INCL RL20000-1,000 lb | List Price: $619.00 | |
| 17860 | Mount ASSY,ITCM 1,000 lb 5/8-11NC Mild Steel Zinc Plated Tension INCL RL20000-1,000 lb | List Price: $619.00 | |
| 17835 | Mount ASSY,ITCM 1,000 lb 3/4-10NC Mild Steel Zinc Plated Tension INCL RL20000-1,000 lb | List Price: $619.00 | |
| 17856 | Mount ASSY,ITCM 1,500 lb 1/2-13NC Mild Steel Zinc Plated Tension INCL RL20000-1,500 lb | List Price: $619.00 | |
| 17861 | Mount ASSY,ITCM 1,500 lb 5/8-11NC Mild Steel Zinc Plated Tension INCL RL20000-1,500 lb | List Price: $609.00 | |
| 17836 | Mount ASSY,ITCM 1,500 lb 3/4-10NC Mild Steel Zinc Plated Tension INCL RL20000-1,500 lb | List Price: $609.00 | |
| 17857 | Mount ASSY,ITCM 2,000 lb 1/2-13NC Mild Steel Zinc Plated Tension INCL RL20000-2,000 lb | List Price: $609.00 | |
| 17862 | Mount ASSY,ITCM 2,000 lb 5/8-11NC Mild Steel Zinc Plated Tension INCL RL20000-2,000 lb | List Price: $619.00 | |
| 17837 | Mount ASSY,ITCM 2,000 lb 3/4-10NC Mild Steel Zinc Plated Tension INCL RL20000-2,000 lb | List Price: $619.00 | |
| 17863 | Mount ASSY,ITCM 2,500 lb 5/8-11NC Mild Steel Zinc Plated Tension INCL RL20000-2,500 lb | List Price: $619.00 | |
| 17838 | Mount ASSY,ITCM 2,500 lb 3/4-10NC Mild Steel Zinc Plated Tension INCL RL20000-2,500 lb | List Price: $619.00 | |
| 30339 | Mount ASSY,ITCM 3,000 lb 3/4-10NC Mild Steel Zinc Plated Tension INCL RL20000-3000LB | List Price: $646.00 | |
| 17864 | Mount ASSY,ITCM 5,000 lb 3/4-10NC Mild Steel Zinc Plated Tension INCL RL20000-5,000 lb | List Price: $842.00 | |
| 17839 | Mount ASSY,ITCM 5,000 lb 1-8NC Mild Steel Zinc Plated Tension INCL RL20000-5,000 lb | List Price: $842.00 | |
| 17840 | Mount ASSY,ITCM 10,000 lb 1-8NC Mild Steel Zinc Plated Tension INCL RL20000-10,000 lb | List Price: $842.00 | |
| 17960 | Mount ASSY,ITCM 15,000 lb 1-1/4-7NC Mild Steel Zinc Plated Tension INCL RL20000-15,000 lb | List Price: $1,756.00 | |
| 17961 | Mount ASSY,ITCM 20,000 lb 1-1/2-6NC Mild Steel Zinc Plated Tension INCL RL20000-20,000 lb | List Price: $2,064.00 |
Replacement parts can only be purchased through trained and authorized dealers. You must be logged in as a dealer to view any available replacement parts.
To locate a dealer in your area, please call us at 1-800-472-6703 or fill out a request online.
