Load Cell Isolators
- Power surges such as those caused by welding or electrical shorts frequently damage load cells and indicators. To prevent such damage, these isolators electrically separate the mechanical assembly from its tension-type load cell.
Load Cell Isolator Dimensions
Part # | Height Thread SizeSafe Load* | Diameter | Safe Load* |
---|---|---|---|
17722 | 3/8-16 UNC | 2.50 in | 600 lb |
17724 | 1/2-13 UNC | 2.50 in | 600 lb |
17726 | 1/2-20 UNF | 2.50 in | 600 lb |
17725 | 1/2-13 UNC | 2.00 in | 3,000 lb |
17723 | 3/8-24 UNF | 2.50 in | 600 lb |
17728 | 1/2-13 UNC x 1/2-20 UNF | 2.50 in | 600 lb |
17732 | 1/4-20 UNC | 1.12 in | 250 lb |
*Do not exceed the safe load |
Resources / Downloads
Parts
Part # | Description | List Price | Cart |
---|---|---|---|
17722 | Isolator,Load Cell 3/8-16 NC FEMx3/8-16NC FEM 2-1/2H 600 lb |
List Price: $48.00 |
|
17724 | Isolator,Load Cell 1/2-13 NC FEMx1/2-13NC FEM 2-1/2H 600 lb |
List Price: $53.00 |
|
17726 | Isolator,Load Cell 1/2-20 NF FEMx1/2-20NF FEM 2-1/2H 600 lb |
List Price: $90.00 |
|
17725 | Isolator,Load Cell 1/2-13 NC FEMx1/2-13NC FEM 2-7/16H 3,000 lb |
List Price: $127.00 |
|
17723 | Isolator,Load Cell 3/8-24 NF FEMx3/8-24NF FEM 2-1/2H 600 lb |
List Price: $95.00 |
|
117728 | Load cell adapter block for conduit |
List Price: $40.00 |
|
117732 | Load Cell,SBM RL2010-10K 10,000lb 40ft 3mv/v 350 Ohm EW IP67 SST Tension Link |
List Price: $1,430.00 |
