MSI Scoreboards Wireless RF

  • Tilt mounting bracket
  • Integrated data repeater
  • AC/DC power supply: 85-265 VAC, 47-440Hz/130-300 VDC
  • RF telemetry via 2.4GHz modem (certain part numbers only)
  • Six high-intensity red digits (double-row discrete LED)
  • Auto Learn mode of communication protocols
  • Hold displayed weight (demand input)
  • Software selectable standstill mode for no updates while in motion
  • Durable weather tight IP66 enclosure
  • Adjustable daylight/night intensity
  • Non-glare contrast filtered lens
  • Mirror (reverse image) feature
  • RS-232, 20 mA and RS-485 communications
  • Scale Core RF (certain models only)
  • Auto sensing 115/230 VAC power supply
  • PEMs for VESA flat-wall mount or side-mounting flange available
  • Polyethylene breather vent inhibits internal moisture buildup

Enclosure:
NEMA Type 4, IP66

Display:
Six-digit long-life LED, 4 in or 6 in

Power:
AC/DC power supply 85-265 VAC, 47-440Hz/130-300 VDC
Radio Link:
Direct sequence spread spectrum at 2.4GHz

Radio Link Effective Range:
Typically 100 ft - 300 ft, line of sight; for longer range consult factory

Standard Antenna:
1/2 wave 2 dBi, articulated

Warranty:
One-year limited

Echo Data Output:
RS-232

Temperature Range:
-40°F–120°F (-40°C–49°C)

22-inch enclosure (4-inch model)

A 22.28 in (565mm) C 3.28 in (85mm)
B 10.96 in (280mm) D 9.80 in (250mm)



31-inch enclosure (6-inch model)

A 30.63 in (780mm) C 3.73 in (95mm)
B 13.94 in (355mm) D 12.77 in (325mm

Resources / Downloads

Title Download Email
MSI Scoreboards Wireless RF Catalog Page Download Email

Parts

MSI Scoreboards Wireless RF

Part # Description List Price Cart
178004 4in LASERLIGHT2 MSI RF Includes ScaleCore RF Kit and Tilt Mounting Bracket

List Price: $2,250.00

178006 6in LASERLIGHT2 MSI XBEE RF Includes ScaleCore RF Kit and Tilt Mount Bracket

List Price: $2,675.00

178341 Display,LaserLight2 4-IN W/Tilt, Bracket ASSY

List Price: $2,140.00

178342 Display,LaserLight2 6-IN W/Tilt, Bracket Assembly

List Price: $2,550.00

Options

Options

Part # Description List Price Cart
139309 ANTENNA KIT LONG RANGE OMNI W/3M COAX

List Price: $460.00

139310 ANTENNA KIT CORNER REFLECTOR 9DBI W/3M COAX

List Price: $455.00

139311 ANTENNA KIT CORNER REFLECTOR 12dBi W/3m COAX

List Price: $485.00

139313 ANTENNA KIT VEHICLE MOUNT 5DBI W/5M COAX

List Price: $140.00

162178 Option Kit Remote Antenna 7000/7001 (Uses Standard Antenna)

List Price: $440.00

197013 Option Kit Remote Antenna Cable TNC (Uses Standard Antenna)

List Price: $470.00

178318 Bracket ASSY,Wall Mount Adjustable Tilt For 4 inch and 6 inch Laserlight2

List Price: $245.00

Replacement Parts

Replacement parts can only be purchased through trained and authorized dealers. You must be logged in as a dealer to view any available replacement parts.

To locate a dealer in your area, please call us at 1-800-472-6703 or fill out a request online.
