Full Scale Output:
1.75 mV/V

Output Resistance:
722 (nominal)

Input Resistance:
700 (nominal)

Material/Finish:
Alloy steel

Temperature:
14° F to 104° F (-10°C to 40°C)

Rated Excitation:
15VDC (5-10V recommended)

Non-linearity:
±0.25% full scale

Insulation Resistance:
2,000 megohms at 50VDC

Seal Type:
Hermetically sealed, IP68

Cable Length:
20 ft or 50 ft

Wire Color Code:
Red - Excitation +
Green - Signal +
White - Signal -
Black - Excitation
Drain Wire - Shield

Warranty:
One-year limited warranty

Resources / Downloads

Title Collateral Wizard Request Download Email Category
Onboard Load Cell Systems for Rigid, Straight-Chassis Vehicles Download Email Onboard Weighing
