Rice Lake RL72019SS Stainless Steel, Double-Ended Beam Load Cell

 A direct replacement for the RL72010MH load cell. It is stainless steel and has a welded seal. Complete with 25 ft of cable and is available in capacities from 5,000 lb to 60,000 lb.

Approvals

Some approval documents are available to view by clicking the icons below.

NTEP Logo LOGO FM CUS

WARNING: Cancer and Reproductive Harm California Proposition 65

Full Scale Output:
3.0 mV/V

Output Resistance:
700 (±5) ohm

Input Resistance:
800 (±30) ohm

Material/Finish:
Stainless steel

Temperature:
Operating:
0 °F to 150 °F (-18 °C to 65 °C)

Seal Type:
Welded-seal, IP68

Safe Overload:
150% full scale

Rated Excitation:
5 to 10 VDC

Nonlinearity:
0.03% full scale

Hysteresis:
0.5% full scale

Insulation Resistance:
5,000 megohm

Cable Length:
25 ft

Cable Color Code:
Red +Excitation
Black –Excitation
Green +Signal
White –Signal

Warranty:
Two-year limited

Approvals:
cFMus
NTEP 21-064

Rated Capacity A B C D E F ØG H
lb/in
5,000 to 20,000 8.12 1.14 6.88 1.44 1.71 1.71 1.00 1/4-18 NPT
30,000 to 60,000 10.25 2.38 8.50 1.88 3.03 3.03 2.00 1/2-14 NPT





Resources / Downloads

Title Download Email
RL72019SS Load Cell Catalog Page Download Email

Title Collateral Wizard Request Download Email Category
Load Cell Wiring Guide Request Download Email Load Cells
Load Cell Selection Guide Request Download Email Load Cells|Weigh Modules
Load Cell and Weigh Module Selection Guide Request Download Email Load Cells|Weigh Modules
Load Cell and Weigh Module Handbook Request Download Email Load Cells|Weigh Modules

Title View Download Email Category
Rice Lake's Load Cell Service, Selection and Speed View Download Email Load Cells

Title Download Email Category
Choosing Load Cells for Tough Applications Download Email Load Cells
Properly Welding on Structures with Load Cells Download Email Load Cells

Parts

Part # Description List Price Cart
194021 Load Cell, DEB RL72019SS 5k 5000lb 25ft 3mv/v 700 Ohm WW SST WS FM IP68

List Price: $1,160.00

194022 Load Cell, DEB RL72019SS 10k 10000lb 25ft 3mv/v 700 Ohm WW SST NTEP III 5M IIIL 10M WS FM IP68

List Price: $1,160.00

194023 Load Cell, DEB RL72019SS 20k 20000lb 25ft 3mv/v 700 Ohm WW SST NTEP III 5M IIIL 10M WS FM IP68

List Price: $1,160.00

194024 Load Cell, DEB RL72019SS 30k 30000lb 25ft 3mv/v 700 Ohm WW SST NTEP III 5M IIIL 10M WS FM IP68

List Price: $1,585.00

194025 Load Cell, DEB RL72019SS 40k 40000lb 25ft 3mv/v 700 Ohm WW SST NTEP III 5M IIIL 10M WS FM IP68

List Price: $1,585.00

194026 Load Cell, DEB RL72019SS 50k 50000lb 25ft 3mv/v 700 Ohm WW SST NTEP III 5M IIIL 10M WS FM IP68

List Price: $1,585.00

194027 Load Cell, DEB RL72019SS 60k 60000lb 25ft 3mv/v 700 Ohm WW SST NTEP III 5M IIIL 10M WS FM IP68

List Price: $1,585.00
