Interface® WMC Tension/Compression Rod End Load Cell

Constructed of stainless steel, environmentally sealed and designed for tension or compression. Capacities range from 15,000 to 200,000 lb.

Request More Information
rl-interface-WMC-tension-compression-rod-end-load-cell

Full Scale Output:
2.0 mV/V

Bridge Resistance:
350 ohm nominal

Material/Finish:
Stainless steel

Temperature:
Operating: -65 °F to 250 °F (-54 °C to 121 °C)

Safe Overload:
150% full scale

Rated Excitation:
15 VDC Max

Nonlinearity:
15 to 30 k: ± 0.10% full scale
100 k: ± 0.15% full scale
200 k: ± 0.20% full scale

Hysteresis:
± 0.15% full scale

Insulation Resistance:
> 5,000 megohm

Connector Pin Out:
A +Excitation
B +Sense
C –Excitation
D –Sense
E –Signal
F +Signal

Warranty:
One-year limited

Rated Capacity A B C D E F
lb/in
15,000 to 50,000 2.00 6.50 2.47 2.50 1.5-12 UNF 1.01
100,000 3.00 10.00 3.97 3.50 2.50-12 UNF 1.28
200,000 4.00 13.00 4.97 4.47 3.50-8 UNF 1.36





Resources/Downloads

Title Download Email
Interface WMC Load Cell Catalog Page Download Email

Title Version Revision Download Email Category Archived
Load Cell and Weigh Module Handbook D Download Email Load Cells|Weigh Modules No

Title Collateral Wizard Request Download Email Category
Load Cell and Weigh Module Selection Guide Request Download Email Load Cells|Weigh Modules

Title Download Email Category
Choosing Load Cells for Tough Applications Download Email Load Cells

Parts

Part # Description List Price Cart/Quote
185079 Load Cell,Rod End WMC-15K Interface 15,000lb Stainless Steel 2mv/v 350 Ohm T/C

List Price: $2,040.00
185080 Load Cell,Rod End WMC-20K Interface 20,000lb Stainless Steel 2mv/v 350 Ohm T/C

List Price: $2,040.00
185081 Load Cell,Rod End WMC-30K Interface 30,000lb Stainless Steel 2mv/v 350 Ohm T/C

List Price: $2,040.00
185583 Load Cell,Rod End WMC-50K 50,000lb Stainless Steel 2mv/v 350 Ohm T/C

List Price: $2,040.00
185082 Load Cell,Rod End WMC- 100K Interface 100,000lb Stainless Steel 2mv/v 350 Ohm T/C

List Price: $3,705.00
185083 Load Cell,Rod End WMC- 200K Interface 200,000lb Stainless Steel 2mv/v 350 Ohm T/C

List Price: $4,400.00

Options

Load Cell Cable Option

Part # Description List Price Cart/Quote
185459 Cable, Interface WMC Rod End Load Cell 10ft with PT06A-10-6S (SR) connector. 15k-200k

List Price: $250.00
