Rice Lake RL32018 Alloy Steel, Single-Ended Beam Load Cell

The Rice Lake RL32018 is an alloy steel single-ended beam cell offered from 250 to 20,000 lb. Each load cell has 20 ft of cable and is FM approved and NTEP certified from 1,000 to 10,000 lb.

Approvals

Some approval documents are available to view by clicking the icons below.

NTEP Logo LOGO FM CUS

WARNING: Cancer and Reproductive Harm California Proposition 65

Full Scale Output:
3.0 mV/V ±0.05% current matched

Output Resistance:
350 (± 3) ohm

Input Resistance:
400 (± 20) ohm

Material/Finish:
Alloy steel, nickel plated

Temperature:
Compensated range
-14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C)

Seal Type:
Environmentally sealed, IP66

Safe Overload:
150% full scale

Safe Sideload:
100% full scale

Rated Excitation:
10 VDC (15 V maximum)

Combined Error:
0.017% full scale

Insulation Resistance:
>5,000 megohm

Deflection:
0.2 to 0.4 mm

Cable Length:
20 ft

Cable Color Code:
Red +Excitation
Black –Excitation
Green +Signal
White –Signal

Warranty:
Two-year limited

Approvals:
cFMus
NTEP 18-106

Rated Capacity A B C D E F G H I J K L M N
lb/in
250 to 500 1.00 0.59 0.96 2.20 1.24 5.12 0.53 0.70 1/2-20 UNF 3.00 1.00 0.62 0.25 0.13
1,000 to 5,000 SE 1.24 0.59 0.96 2.20 1.24 5.12 0.53 0.70 1/2-20 UNF 3.00 1.00 0.62 0.25 0.13
5,000 LE to 10,000 1.50 - 1.45 2.99 1.50 6.75 0.80 0.70 3/4-16 UNF 3.75 1.50 0.75 - -
15,000 to 20,000 2.00 - - 4.00 2.00 8.75 1.06 - 1-14 UNS 4.90 2.00 1.00 - -





Resources / Downloads

Title Download Email
RL32018 Load Cell Catalog Page Download Email

Title Collateral Wizard Request Download Email Category
Load Cell Wiring Guide Request Download Email Load Cells
Load Cell Selection Guide Request Download Email Load Cells|Weigh Modules
Load Cell and Weigh Module Selection Guide Request Download Email Load Cells|Weigh Modules
Load Cell and Weigh Module Handbook Request Download Email Load Cells|Weigh Modules
Your First Choice in Load Cells Download Email Load Cells

Title View Download Email Category
Rice Lake's Load Cell Service, Selection and Speed View Download Email Load Cells

Title Download Email Category
Choosing Load Cells for Tough Applications Download Email Load Cells
Properly Welding on Structures with Load Cells Download Email Load Cells

Parts

NTEP Certified

Part # Description List Price Cart
189152 Load Cell,SEB RL32018- 1000lb 20ft 3mv/v 350 Ohm NTEP III 5M Alloy FM WW IP66

List Price: $312.00

191732 Load Cell, SEB RL32018 1500lb 20ft 3mv/v 350 Ohm NTEP III 5M Alloy FM WW IP66

List Price: $312.00

189153 Load Cell,SEB RL32018- 2000lb 20ft 3mv/v 350 Ohm NTEP III 5M Alloy FM WW IP66

List Price: $312.00

189154 Load Cell,SEB RL32018- 2500lb 20ft 3mv/v 350 Ohm NTEP III 5M Alloy FM WW IP66

List Price: $312.00

189155 Load Cell,SEB RL32018- 3000lb 20ft 3mv/v 350 Ohm NTEP III 5M Alloy FM WW IP66

List Price: $312.00

189156 Load Cell,SEB RL32018- 4000lb 20ft 3mv/v 350 Ohm NTEP III 5M Alloy FM WW IP66

List Price: $312.00

189157 Load Cell,SEB RL32018- 5000LBSE 20ft 3mv/v 350 Ohm NTEP III 5M Alloy FM WW IP66

List Price: $312.00

189158 Load Cell,SEB RL32018- 5000lbLE 20ft 3mv/v 350 Ohm NTEP III 5M Alloy FM WW IP66

List Price: $398.00

189159 Load Cell,SEB RL32018- 10000lb 20ft 3mv/v 350 Ohm NTEP III 5M Alloy FM WW IP66

List Price: $398.00

Non-NTEP Certified

Overbraid Cable

Options

No options found for this product

Replacement Parts

Replacement parts can only be purchased through trained and authorized dealers. You must be logged in as a dealer to view any available replacement parts.

To locate a dealer in your area, please call us at 1-800-472-6703 or fill out a request online.
