Honeywell M-4206/M-4210 Mark II Industrial Printer

  • 203 dpi (8 dots/mm) print resolution (M4308, 300 dpi)
  • Lightweight die-cast aluminum frame
  • Supplies loading diagram embossed into the frame
  • Collapsible ribbon hub for loading and unloading of ribbons
  • Media window
  • Scaleable font engine
  • USB, serial and parallel communications
  • Reverse fields/mirror image (fonts/graphics can be printed as a normal or reverse image)
  • Real-time clock (M-4210)
  • Support CD-ROM (contains DMX EM conf. tool, Windows® print drivers an manuals)
  • Line mode
  • LCD Graphical Display

Approvals

Some approval documents are available to view by clicking the icons below.

CE Mark UL Listed CSA

WARNING: Cancer and Reproductive Harm California Proposition 65

Compact Industrial Printer

The compact M-Class industrial printer has a smaller footprint ideal for space limitations. The modular design of the printer makes maintenance and part replacement easy, and the flexible design allow a variety of options to be upgraded in the field. With a broad range of connectivity to meet diverse application requirements and easy integration into any network, the M-class is designed for any level of user. The easy-to-navigate LCD graphics display for menu viewing and printer function-control.

Print Speed:
M-4206 Mark II: 2 in to 6 in per second
(51 mm to 152 mm)
M-4210 Mark II: 2 in to 10 in per second
(51 mm to 152 mm)
M4308: 2 in to 8 in per second
(51 mm to 203 mm)

Supply Roll Capacity:
8 in (203 mm) O D on 1.5 in to 3.0 in
(38 mm to 76.2 mm) cores
Fanfold stock accepted from rear and bottom of printer

Bar Code Modulus:
5 mil to 55 mil “X” dimension in picket fence or ladder orientations

Media Width:
0.75 in to 4.65 in (17 mm to 118 mm)

Media Type:
Roll fed or fan-fold materials, die-cut or continuous labels; perforated or continuous tag/ticket stock

Print Length:
0.25 in to 99 in (6 mm to 2,475 mm)

Media Thickness:
0.0025 in to .01 in (.0635 mm to .254 mm)

Ribbons:
Industry standard ribbon widths; 1 in (25 mm) ribbon core, 1,476 ft (450 m) in length

Bar Codes:
Code 3 of 9, UPC-A, UPC-E, Interleaved
2 of 5, Code 128, EAN-8, EAN-13, HIBC,
Codabar, Plessey, UPC 2 and 5 digit
addendums, Code 93, Postnet, UCC/EAN
Code 128, Telepen, UPS MaxiCode, FIM,
PDF417, USD-8, Datamatrix, QR Code, Aztec,
TLC 39, Micro PDF417, RSS

Graphics Supported:
.PCX, .BMP and .IMG files

Memory:
M4206: 8 MB RAM (8 MB FLASH), 1 MB user available
M4210: 16 MB RAM (8 MB FLASH), 3 MB user available

Construction:
Metal

Interfaces:
USB, Centronics® parallel port,
RS-232 (DB-9F) at 600 to 38,400 BPS

Processor:
M-4206 Mark II Dragonball, 100 MHz
M-4210 Mark II Dragonball, 150 MHz

Power Source:
Auto-sensing 90 to 132 or 180 to 264 VAC at 47 to 63 Hz; specify appropriate power supply and cord when ordering

Operating Temperature:
40° F to 95° F (4° C to 35° C)

Dimensions:
(H x W x D): 10.21 x 10.10 x 18.19 in
(259 x 257 x 462 mm)

Weight:
27 lb

Approvals:
UL listed, CSA certified, CE marked, TUV-GS safety standards, FCC Class A
emissions, RoHS and WEE compliant

Warranty:
One-year limited warranty.
One year or 1 million linear inches on original print head.
90 days on replacement print head

Resources / Downloads

Title View Email Category Type
Give Your Balance a Brain View Email Precision Balances Articles

Title Download Email
Honeywell M-4206 Mark II/M-4210 Mark II Catalog Page Download Email

Title Version Revision Download Email Category Archived
Honeywell Programming Language and Storage Download Email Printers No

Title Download Email
Custom Label Format Form Download Email

Title Download Email
Honeywell Label Printers Replacement Parts Catalog Page Download Email

Title Version Size Release Date Download Email
Honeywell Label Format Strings 1 0B 10/19/2009 Download Email
Revolution Format Examples DPL 1 7.6 KB 11/11/2011 Download Email

Parts

M-4210 Mark II

Part # Description List Price Cart
103366 Printer,Label M-4210 MARK II, Direct Thermal, Graphical Display, 203DPI, 10IPS, Ethernet

List Price: $1,645.00

103367 Printer,Label M-4210 MARK II,Direct Thermal, Graphical Display, 203DPI, 10IPS, Serial, Parallel or USB

List Price: $1,395.00

108891 Printer,M-4210 Mark II Direct Thermal, Graphical Display, 203DPI, 10IPS, Serial, USB or Parallel, Internal Rewind, Peel and Present OPT

List Price: $1,800.00

Consult Label printer, M-4308 models by request

Call for price

M-4206 Mark II

Options

Misc Options

Part # Description List Price Cart
76729 Printer OPT,Thermal Transfer, M Class Mark II

List Price: $100.00

76730 Printer OPT,Peel Mechanism and Present Sensor (Requires Internal Rewinder) M Class

List Price: $220.00

76731 Printer OPT,Internal Rewinder, M Class

List Price: $210.00

76732 Printer OPT,Present Sensor, M Class

List Price: $135.00

76733 Printer OPT,Cutter Kit 10 Mil Stock, M Class

List Price: $520.00

35664 Label,Pre-Saturated Cards 4x6 25/Box for 4in Wide Printers

List Price: $60.00

93181 Film,Printhead Cleaning 4IN Wide, 3/Box

List Price: $21.50

76734 Printer OPT,M-4206 Manual Programmers Manual

List Price: $135.00

77562 LIT,Manual M-4206 Operator Manual

List Price: $26.50

103372 Card,Internal Ethernet M-4206 and M-4210 Models produced after 11/12/07

List Price: $265.00

103373 Card,Wireless Ethernet M-4206 and M-4210 Models produced after 11/12/07 Does Not Include USB Port

List Price: $510.00

103374 Card,USB HOST, LAN and Wireless card, M-4210 Models 13 and Wireless card

List Price: $550.00

Cables

Label Stock/Ribbon (W x L)

Print Head

Replacement Parts

Replacement parts can only be purchased through trained and authorized dealers. You must be logged in as a dealer to view any available replacement parts.

To locate a dealer in your area, please call us at 1-800-472-6703 or fill out a request online.
