Motor Truck Scale Electronic Weigh Module Conversion Kit

Complete Kit Includes

• Four, six or eight Translink™ mounting assemblies with NTEP Certified RL75040 or RL75223 welded-seal load cells
• One JB8SP NEMA Type 4X signal-trim junction box with individual and section trimming capability (six- and eight-mount kits) or one JB4SP NEMA Type 4X signal-trim junction box (four-mount kits)
• One UJB3T6 DC transient protector
• 100 ft of hostile environment EL147HE SURVIVOR® load cell cable

Standard Features

• Capacity (per module): 25,000 to 100,000 lb
• Cost and time efficient installation; no need to remove weighbridge
• Converts existing scale capacities of 40,000 to 300,000 lb
• Four, six or eight-mount kits for two, three or four section conversions
• Translink heavy-capacity mounting assemblies
• Free movement in all directions in the horizontal plane with virtually no friction
• Completely self-centering
• Requires no check rods
• Compatible with VPG® Sensortronics® 65040A or VPG® Revere 5223 load cells

Applications

• Updating existing mechanical motor truck scales
• Replacing unsatisfactory electronic motor truck scales
• Conversion of heavy-capacity scales into fully electronic vehicle scales where the existing scale cannot be removed
