Low-profile, single point load cell designed for direct mounting in low-cost platforms. Anodized aluminum construction is combined with two-beam machined technology to provide an affordable load cell option. Capacities range from 3 to 35 kg. Complete with 0.5 or 3 m of load cell cable.
Some approval documents are available to view by clicking the icons below.
WARNING: Cancer and Reproductive Harm California Proposition 65
| Part # | Description | List Price | Cart/Quote |
|---|---|---|---|
| 41135 | Load Cell,SPT 1022-3kg 1.5ft TH 2mV/V 350 OHM NTEP III 5 S FM Al IP66 | List Price: $150.00 | |
| 41136 | Load Cell,SPT 1022-5kg 1.5ft TH 2mV/V 350 OHM NTEP III 5 S FM Al IP66 | List Price: $150.00 | |
| 41137 | Load Cell,SPT 1022-7kg 1.5ft TH 2mV/V 350 OHM NTEP III 5 S FM Al IP66 | List Price: $150.00 | |
| 41138 | Load Cell,SPT 1022-10kg 1.5ft TH 2mV/V 350 OHM NTEP III 5 S FM Al IP66 | List Price: $150.00 | |
| 41139 | Load Cell,SPT 1022-15kg 1.5ft TH 2mV/V 350 OHM NTEP III 5 S FM Al IP66 | List Price: $150.00 | |
| 41141 | Load Cell,SPT 1022-30kg 1.5ft TH 2mV/V 350 OHM NTEP III 5 S FM Al IP66 | List Price: $150.00 | |
| 41142 | Load Cell,SPT 1022-35kg 1.5ft TH 2mV/V 350 OHM NTEP III 5 S FM Al IP66 | List Price: $150.00 |
