SCT-30 Signal Conditioning Transmitter
- LCD display
- Powers up to eight (350 ohm) load cells in parallel (with a 24-bit A/D converter)
- A/D converter 24-bit 4.8 kHz
- 16-bit analog output: 0-20 mA, 4-20 mA, 0-5 V, 0-10 V, ±5 V, and ±10 V
- Mounting on Omega/DIN rail for back panel or junction box
- Diagnostic message for load cell disconnect and over-capacity errors
Approvals
Some approval documents are available to view by clicking the icons below.
WARNING: Cancer and Reproductive Harm California Proposition 65
Maximum Control, Miniature Size
For PLC systems that require weight data from a scale, Rice Lake’s compact SCT-30 transmitter delivers equivalent signal-conditioning function without the cost or bulk of a full-size weight indicator/controller.
Rice Lake's SCT-30 models are DIN-rail mountable within a cabinet or control panel, where they convert a scale’s load cell signal to serial or analog output. Technicians and operators find the analog output signal particularly useful for monitoring hopper filling and discharge. Unlike many other signal transmitters, Rice Lake SCTs have their own integrated display, with annunciators for unit and weighing status, and push buttons or toggle switch and digital rotary for zero, tare and setpoint entry—ultimately simplifying scale setup, calibration and operation.
SCT-30 Signal Conditioning Transmitter Specifications
|
Power: Power Consumption: Excitation Voltage: Analog Signal Sensitivity: A/D Sample Rate: Resolution: |
System Linearity: Communication Ports: Analog Output: Display: Keys/Buttons: |
Dimensions: Temperature & Humidity: Rating/Material: Weight: Warranty: Approval: |
Resources / Downloads
Parts
| Part # | Description | List Price | Cart |
|---|---|---|---|
| 156794 | Indicator,SCT30 SCT30-AN, 12-24VDC, Analog Output, and RS485 Serial Port DIN Mount, Displays mV and Analog Output Signal Only. Does Not Display Weight. |
List Price: $430.00 |
|
| 156834 | Indicator,SCT30 SCT30-AN, Enclosed in a Plastic Junction Box, 12-24VDC, Analog Output and RS485 Serial Port. |
List Price: $595.00 |
Options
| Part # | Description | List Price | Cart |
|---|---|---|---|
| 88792 | Power Supply,IDEC 12VDC DIN Rail Mount, 1.3 Amp, Input: 85 to 264 VAC, 100 to 370 VDC 15W |
List Price: $140.00 |
|
| 119244 | Power Supply,24VDC 1.3A Din Mount Input 90 to 264VAC,120 to 370VDC, UL E135494 |
List Price: $160.00 |
|
| 131129 | Lit,Manual SCT 10 Series Sct Weight Transmitter |
List Price: $25.00 |
|
| 199707 | End Clamp, Left and Right set with Clip for DIN 35 Rail for SCT-40 |
List Price: $11.00 |
