BenchPro™ BP-P Postal Digital Scale

  • Simple operation, easy to set up
  • Large six-digit backlight LCD display with 1-inch (29 mm) characters protected by heavy-duty tempered glass
  • Powered USB HID point of sale interface, kg model only
  • Nine-pin RS-232 interface for use with SMA and NCI protocols
  • Four AA alkaline battery operation for portability
  • Gravitational compensation allows for adjustment of factory calibration to meet your local gravity setting, non-approved

Approvals

Some approval documents are available to view by clicking the icons below.

NTEP Logo LOGO Measurementcanada Approved BW CE Mark

WARNING: Cancer and Reproductive Harm California Proposition 65

Multiple Range Postal Scale

The BenchPro BP-P digital postal scale is ideal for small package weighing. The die-cast aluminum housing, stainless steel weigh platter and optional battery-power combine for a light-weight, portable weighing option.

Power:
In-line power supply (included)

Input:
100 to 240 VAC, +10% -15%, 3-wire w/ground
Terminated with standard USA 3-prong plug

Output:
12 V at 0.1 Amps DC minimum

Frequency:
50/60 Hz ±3 Hz

Power supply approvals:
UL, CE, EN, CUL

Battery Type:
Four AA alkaline batteries, 6 V, with low battery indication at 4.3 volts

Battery Life:
50 to 250 hrs depending on backlight and auto-shutdown settings

Excitation:
3.0 mV/V

Resolution:
Internal: 500,000 counts

USB HID:
USB 2.0 full speed; Vendor ID: 1C19; Product ID: 0002

Divisions (multi-range):
kg triple range:
0 to 5 kg × 0.001 kg
0 to 10 kg × 0.002 kg
0 to 35 kg × 0.01 kg
lb/oz dual range:
0 to 7 lb × 0.05 oz
0 to 70 lb × 0.2 oz

Divisions (Multi-Interval):
kg triple interval:
0 to 5 kg × 0.001 kg
5 to 10 kg × 0.002 kg
10 to 35 kg × 0.01 kg
Lb/oz dual interval:
0 to 7 lb × 0.05 oz
7 to 70 lb × 0.2 oz

Material:
Display: ABS plastic housing
Scale base: Die-cast aluminum load bridge and base housing with stainless steel weight platter

Dynamic Response:
Response time for stable weight:
0 to 1,000d, 1,000 ms, maximum mean average
1,000d +, 1,500 ms, maximum mean average

Overload Protection:
Corner and center overload protection

Display:
Large six-digit backlight LCD display with 1-inch (29 mm) Characters protected by heavy-duty tempered glass

Annunciators:
Six: zero, gross/brutto, net, W1/W2/W3 multi-range

Keys/Buttons:
Three: units, on/off, F1 (Tare is not applicable)
Minimum key press life of 500,000 cycles

RS-232 Cable (Included):
10 ft DB 9-pin male to female, straight pass-through

USB Cable (Included):
46 in (1,168 mm) A/B type USB cable

Warranty:
Two-year limited

Approvals:
NTEP 17-002
Canada Weights and Measures: AM-6050
CE Marked

Dimensions
A 12.00 in C 14.50 in
B 14.00 in D 2.70 in
Note: 1 in = 25.4 mm



Resources / Downloads

Title View Email Category Type
The Diversity of Digital Bench Scale Systems Email Bench Scales Articles

Title Download Email
BenchPro BP-P Catalog Page Download Email

Title Version Revision Download Email Category Archived
BenchPro BP-P Postal Digital Scale Operation Manual G Download Email Platform Scales|Postal / Shipping Scales No

Title Download Email
BenchPro BP-P, BP-S, BP-R Replacement Parts Catalog Page Download Email

Title Collateral Wizard Request Download Email Category
BenchPro BP-P Series Request Download Email Postal / Shipping Scales

Title View Download Email Category
BenchPro™ Series Shipping and Postal Digital Scale View Download Email Postal / Shipping Scales|Bench Scales
ScaleTalk: What's the Difference Between Multi-Range & Multi-Interval View Download Email Bench Scales

Parts

Part # Description List Price Cart / Quote
187832 Scale, BenchPro Series Model BP-P 1214-35kg capacity triple range Scale with Stainless Steel Weight platter

List Price: $625.00

195741 Scale, BenchPro Series Model BP-P 1214-35kg capacity triple interval Scale with Stainless Steel Weight platter

List Price: $625.00

192361 Scale, BenchPro Series Model BP-P 1214-70lb capacity dual range Scale with Stainless Steel Weight platter

List Price: $625.00

195742 Scale, BenchPro Series Model BP-P 1214-70lb capacity dual interval Scale with Stainless Steel Weight platter

List Price: $625.00

Options

Part # Description List Price Cart / Quote
174783 Bracket and Post, Option Bench Pro Series, Model BP 1214, Height 10 inches

List Price: $50.00

180901 Display,Customer Bench Pro Series, with 68in cable and capacity labels

List Price: $72.00

174784 Remote Display,Bench Pro Series, with 68in cable and capacity labels 53YJ90

List Price: $88.00

183103 Mount,Display Bench Pro Scale 16in Stand

List Price: $215.00

178501 Adapter,USB Serial FTDI US232R-100, 3.28 ft, iDim Series for use with RLWS indicator and Postal Scales

List Price: $60.00
