Product PDF

Ready-n-Weigh Bench Scale System CW-90B Scale Base 680 Indicator

Package includes scale with IP67 aluminum environmentally sealed load cell
with an indicator and 12-inch column
Factory calibrated with indicator setup and configured for 5,000 divisions
Scale includes rubber feet to provide exceptional traction and avoid scratching surfaces along with removable top cover for ease of cleaning
AC power 100 to 240 VAC
LCD backlit indicator display for a variety of environments
Battery backed time and date
Standard RS-232 serial ports for connecting to a variety of peripherals
Ethernet TCP/IP comes standard

Request More Information

Approvals

Some approval documents are available to view by clicking the icons below.

WARNING: Cancer and Reproductive Harm California Proposition 65

HD View

Complete Bench Scale Package with CW-90B Light-capacity Bench Scale and 680 Synergy Series Indicator

Rice Lake’s CW-90B light-capacity bench scale has 304 stainless steel construction and contains an IP67 environmentally sealed aluminum load cell, ensuring it can endure tough environments. The CW-90B is available in capacities up to 100 pounds.

This package pairs the 680 Synergy Series digital weight indicator with the CW-90B. Rice Lake’s 680 has an LED display, battery-backed time and date, a full numeric keypad, and multiple communication ports. Constructed with durable 304 stainless steel and able to withstand harsh washdowns, it maximizes process efficiency in virtually any environment or application.

CW-90B Bench Scale Specifications

Load Cell, NTEP Certified:
IP67 aluminum and environmentally sealed

Scale Construction:
304 stainless steel

Maximum Overload:
180% to 200% depending on capacity

Overload Protection:
Five-point, independently adjusted

Scale Frame:
AISI304L, straight line finish, Ra = 45 +/- 10

Scale Cover:
AISI304L, straight line finish, Ra = 45 +/- 10

Cable Length:
34 in

Compensated Temperature Range:
14 °F to 104 °F (-10 °C to 40 °C)

Approvals:
NTEP 95-072, Class III 5,000 d
Measurement Canada AM-5082
CE
cULus

Warranty:
Two-year limited

680 Indicator Specifications

Communication Ports:
Two RS-232 (three-wire)
RS-485/422 (two-wire or four-wire)
Micro USB (device)
Ethernet TCP/IP (10/100)

Display:
Seven 0.8-inch tall, seven-segment digits

Status Annunciators:
Eight LED annunciators

Keys/Buttons:
Flat membrane panel, tactile feel
(18 buttons plus ON/OFF)

Rating/Material:
Rating: IP69K (IP66 with RJ45)
Material: AISI 304 Stainless Steel

Approvals:
NTEP 19-021
Measurement Canada AM-6121C
cULus Listed
CE Marked

Warranty:
Two-year limited
