RoughDeck® AX Axle Scale

  • System includes two platforms with anchor brackets and four on/off ramps with anchor tabs (anchor bolts not included)
Scale
  • (W x L x H): 32 x 84 x 6 in
  • Axle capacity - tandem platforms - 60,000 lb (two scales 30,000 lb each)
  • Includes (2) 3/4-10 NC eye bolts
  • Contains four environmentally sealed, IP67 20,000 lb single-ended shear beam load cells per platform
  • Treaded top plate with side access junction box
  • JB4SS TuffSeal® signal trim junction box
  • Top access foot adjustment holes
  • Carbon steel captured ball feet
  • 20 ft SURVIVOR® EL147HE cable
  • Non-Legal for Trade
Ramps
  • (W x L x H) 32 x 60 x 6 in
  • Treaded top plate

Maintain accuracy and accountability even in temporary site applications with the RoughDeck AX. This portable, economical option for vehicle and truck weighing is built tough, using time-tested Rice Lake construction. The RoughDeck AX provides a durable and consistent scale for monitoring overloaded and underloaded axle weight.

The RoughDeck AX system includes four on/off ramps and two treaded top plate platforms. Two tandem scale platforms provide axle capacity measurement up to 60,000 pounds. Combined with the TuffSeal® signal trim junction box and SURVIVOR EL147HE cable, the RoughDeck AX system is the ideal portable solution for onsite vehicle weighing.

End Loading Capacity:
133% full scale at 30,000 lb
Warranty:
Load cells two years, all other components one-year limited warranty

Dimensions
A 84.0 in (213.36 cm) E 6.0 in (15.24 cm)
B 32.0 in (81.28 cm) F 1.0 in (2.54 cm)
C 205.5 in (521.97 cm) G 0.75 in (1.91 cm)
D 38.75 in (98.42 cm)

Resources / Downloads

Title View Email Category Type
No Waste of Energy View Email Vehicle Scale System Application Story

Title Download Email
RoughDeck AX Catalog Page Download Email

Title Version Revision Download Email Category Archived
SURVIVOR RoughDeck AX Installation & Operation Manual D Download Email Axle Scales No

Parts

RoughDeck AX Axle Scale Parts

Part # Description List Price Cart
107637 Scale, Axle Roughdeck AX Includes 2 scales (30,000lb each) and 4 ramps

List Price: $16,500.00

Options

No options found for this product

Replacement Parts

Replacement parts can only be purchased through trained and authorized dealers. You must be logged in as a dealer to view any available replacement parts.

To locate a dealer in your area, please call us at 1-800-472-6703 or fill out a request online.
