CLS-920i Forklift Scale Display

  • (W x H) 4.6 in x 3.4 in, back lit LCD graphical display (320 pixels x 420 pixels)
  • Standard program
    • Weight indication
    • Configuration
    • Calibration
    • Diagnostics
  • Front panel calibration
  • On/Off switch to conserve forklift battery life
  • Painted mild steel enclosure
  • Two piece top cage indicator mounting assembly with vibration mounts
  • Two available RS-232 ports for added options of scanner, Wi-Fi or printer
  • 10-60 VDC power supply for use on gas powered or electric forklifts

Note: For custom user program please contact the factory

Approvals

Some approval documents are available to view by clicking the icons below.

NTEP Logo LOGO Measurementcanada Approved BW

WARNING: Cancer and Reproductive Harm California Proposition 65

Flexibility. Intelligence. Programmability.

The CLS-920 is a version of the 920i specifically designed for the CLS forklift scale. It incorporates the flexibility, intelligence and programmability of the 920i in a smaller enclosure with a DC power supply for use on forklifts. The standard program offers weight indication, configuration, calibration and diagnostics specific to the CLS. Customize it for your application with an optional user program.

Power:
Line voltage: 10 – 60 VDC, DC Input
Power consumption: 1.5 A max fused at 5.0

Operating Temperature:
Legal: 14° F to 104° F (-10˚ C to 40˚ C)
Industrial: 14° F to 122° F (-10˚ C to 50˚ C)

Wireless LAN Option:
Contains FCC ID: R68WIPORATG
Range: Up to 328 ft indoors
Operating frequency: ISM 2.4 GH

Warranty:
Two-year limited warranty

Approvals:
NTEP CC 06-074, 5,000 lb only, Class III, 1,000d
Measurement Canada AM-5893, Class III

Dimensions
A 9.54 in (242.3 mm)
B 7.20 in (182.9 mm)
C 9.71 in (246.6 mm)
D 5.82 in (147.8 mm)



Resources / Downloads

Title Download Email
CLS-920i Catalog Page Download Email

Title Version Revision Download Email Category Archived
CLS-920i Daily Operation Card Download Email Forklift No
CLS-920i WLAN Installation Instructions A Download Email Forklift No

Title Download Email
Forklift Scales Questionnaire Download Email

Title Collateral Wizard Request Download Email Category
CLS Series Forklift Scales Request Download Email

Title Version Size Download Email
Fc5Vm9Rpf538$%C 1.04.00 172.7 KB Download Email

Title View Download Email Category
Weigh, Transfer and Collect Data with Forklift Scales View Download Email

Parts

Part # Description List Price Cart
162282 Scale PKG,CLS920i,iQube2 34in.,Wired,5,000lb,10-60VDC With Turck Connect Load Cells

List Price: $9,060.00

Consult Consult factory for CLS-920i package for forklift sizes other than 34 in x 16 in

Call for price

Options

Part # Description List Price Cart
166161 Power Line Filter, CLS DC EMI FIlter, 0-75 VDC input voltage, 100 Vdc surge.

List Price: $95.00

167498 Cable,Extension 2 Meters 125395 Coiled Cable Extension, Straight, Molded Turk PN BSM BKM 5-084-2

List Price: $160.00

188193 CLS Calibration Hook Set

List Price: $245.00

Consult Wi-Fi option for CLS-920i

Call for price

Consult Bluetooth Option for CLS-920i, CLS-M, CLS-IM

Call for price

Consult Cableless option, order upgrade that also includes two batteries and charger

Call for price

Consult DC to DC converter, chassis mount

Call for price

Replacement Parts

Replacement parts can only be purchased through trained and authorized dealers. You must be logged in as a dealer to view any available replacement parts.

To locate a dealer in your area, please call us at 1-800-472-6703 or fill out a request online.
